INPUT
Type 1/4" TRS connector, balanced
Impedance approx. 20 kohms, balanced
approx. 10 kohms, unbalanced
CMRR 40 dB typ. @ 1 kHz
PHONES OUT
Type 1/4" TRS connector, stereo
Impedance min. 100 ohms
Max. output level +13 dBu @ 100 ohms load
LINK OUT A
Type 1/4" TRS connector, balanced
SYSTEM SPECIFICATIONS
Frequency response 10 Hz to 120 kHz, -3 dB
Dynamic range 108 dB, 10 Hz to 22 kHz (100 ohms load)
Distortion 0.007 % typ. (100 ohms load)
Crosstalk < 80 dBu @ 1 kHz
Signal-to-noise ratio 10 Hz to 22 kHz < 95 dB @ 0 dBu, a-weighted
AMPLIFIER
Max. output level +21 dBm / 124 mW (100 ohms load)
Min. output impedance 47 ohms
POWER SUPPLY
Mains connection external power supply, 9 V / 750 mA
Mains voltage
