Minimum computer-system requirements
Windows
- Windows Vista, Windows 7 (32- and 64-bit)
- Intel Pentium 4 1.6GHz processor or AMD Athlon 64 3000+ (Turion) (2.8GHz or faster recommended)
- 1GB RAM (2GB or more recommended)
Macintosh
- Mac OS X 10.6 (Snow Leopard) or later (32- and 64-bit)
- Intel Core 1 Solo 1.5GHz processor (Intel Core Duo or Intel Xeon processor recommended)
- 1GB RAM (2GB or more recommended)
Windows and Macintosh Systems
- USB 2.0 Port
- Internet connection recommended
- DVD-ROM drive (required to install Studio One Artist)
Microphone Inputs
- Connector Type: Combo, XLR, female, balanced
- Mic Preamp EIN: -133dB, 20kHz BW, max gain, Rs=40 ohm, A-wtd
- Frequency Response: 20Hz - 20kHz, ±0.25dB, unity gain
- THD+N: 0.002%, +4dBu, 1kHz, unity gain, 22kHz BW, A-wtd
- S/N Ratio: 97 dB, +4dBu, 1kHz, unity gain, 22kHz BW, A-wtd
- Gain Control Range: -15dB to +65dB
- Input Max Headroom: +16dBu, < 0.5% THD
- Input Impedance: 1.7k ohm
- Phantom Power: +48VDC, 10mA total
Line Inputs
- Connector Type: Combo, 1/4" TS, female, unbalanced
- Frequency Response: 20Hz - 20kHz, ±0.25dB, unity gain
- THD+N: 0.002%, +4dBu, 1kHz, unity gain, 22kHz BW, A-wtd
- S/N Ratio: 98dB, +4dBu, 1kHz, unity gain, 22kHz BW, A-wtd
- Gain Control Range -20dB to +20dB
- Input Max Headroom +21dBu, < 0.5% THD
- Input Impedance 10k ohm
Instrument Inputs
- Connector Type: Combo, 1/4" TS, female, unbalanced
- Frequency Response 20Hz - 20kHz, ±0.25dB, unity gain
- THD+N: 0.003%, +4dBu, 1kHz, unity gain, 22kHz BW, A-wtd
- S/N Ratio: 89dB, 0dBu, 1kHz, unity gain, 20kHz BW, unwtd
- Gain Control Range: -30dB to +50dB
- Input Max Headroom: +21 dBu, < 0.5% THD
- Input Impedance: 1M ohm
Analog Outputs
- Connector Type: 1/4" TRS, female, impedance balanced
- Frequency Response: 20Hz - 20kHz, ±0.25dB
- THD+N: 0.003%, 1kHz, 22kHz BW, A-wtd
- S/N Ratio: 109dB, 1kHz, 22kHz BW, A-wtd
- Output Level: +10dBu, <0.5% THD
- Output Impedance: 51 ohm
Headphone Outputs
- Connector Type 1/4" TRS, female, stereo
- Maximum Power 120mW/ch @ 60 ohm load
- Frequency Response: 20Hz - 20kHz, ±0.5dB, max gain
- THD+N: 0.01%, 1kHz, max gain, 20kHz BW, A-wtd
- S/N Ratio: 96dB, 1kHz, max gain, 20kHz BW, A-wtd
Power
- External Power Adapter +18VDC, 2.6A, center-positive
- Connector Type 5.5 mm OD, 2.1 mm ID, 9.5 mm length
Digital
- ADC Dynamic Range: 114dB, 48kHz, A-wtd
- DAC Dynamic Range: 114dB, 48kHz, A-wtd
- Host Interface: USB 2.0 high-speed
- Bit Depth: 24-bit
- Sample Rates: 44.1kHz, 48kHz, 88.2kHz, 96kHz
- Latency: 2.8 ms - 6 ms, analog in to out
- ADAT: Optical I/O Toslink connectors, ADAT/SMUX formats
- S/PDIF: I/O RCA female connectors
- Word Clock: Output BNC connector, 4.5 Vpp @ 75 ohm load
- MIDI I/O: 5-pin DIN connectors
