• Input : (3) analog line inputs/(2) AES digital inputs (shared connectors), (1) RTA mic input
• Input Connectors : (3) female XLRs (2 selectable between analog/AES digital audio formats), (1) female XLR RTA mic input
• Input Type : Electronically balanced/RF filtered
• Input Impedance : > 30 kΩ, balanced line to line
• Max Input Level (line inputs) : > +28 dBu, balanced, ≤1% THD
• CMRR : > 50 dB @ 1 kHz
• RTA Mic Preamp Phantom Power : +48 VDC
• Output : (6) Line Outputs
• Output Connectors: Male XLR
• Output Type : Electronically balanced, RF filtered
• Output Impedance : 120 Ω, balanced line to line
• Max Output Level : +22 dBu, balanced, ≤1% THD
• Alignment Delay : Up to 1000 ms per output channel
• A/D Converter : 24-bit with dbx Type IV™ Conversion System
• A/D Dynamic Range : 117 dB A-weighted, 114 dB unweighted, 22 kHz BW
• Type IV Dynamic Range : 129 dB with transient material, A-weighted, 22 kHz BW; 126 dB with transient material, unweighted, 22 kHz BW; 121 dB typical with program material, A-weighted, 22 kHz BW
• D/A Converter : 24-bit
• D/A Dynamic Range : 116 dB A-weighted, 113 dB unweighted, 22 kHz BW
• Internal Processing Wordlength : 32-bit floating point
• Supported Sample Rates : 48/96 kHz (32-192 kHz using sample rate conversion)
• System Performance Dynamic Range : 114 dB A-weighted; 110 dB unweighted
• THD+Noise : 0.0025% typical at +4 dBu, 1 kHz, 0 dB input gain
• Frequency Response : 20 Hz – 20 kHz, +0 /- 0.5 dB
• Interchannel Crosstalk : < -97 dB, -105 dB typical 20-20 kHz, +4 dBu, all channels measured
• Latency : Analog input to output: 2.57 ms (48 kHz), 2.28 ms (96 kHz); Digital AES input to output: 2.31 (48 kHz), 2.15 ms (96 kHz)
