Frequency Response - 65 Hz - 18 kHz ±3 dB / 50 Hz - 20 kHz -10 dB;
Nominal Dispersion - 90º H X 50º V @ -6 dB Points,
Directivity Factor (Q) - 10.4, Directivity Index (DI) - 10.2
Power Handling (IEC) Passive - 800 W continuous, 3,200 W peak;
Power Handling (IEC) Bi-amp - LF: 800 W continuous, 3,200 W peak / HF: 75 W continuous, 300 W peak
Sensitivity - 96 dB (1 W @ 1 m);
Maximum SPL Passive - 125 dB continuous, 131 dB peak;
Maximum SPL Bi-Amp - LF: 125 dB continuous, 131 dB peak / HF: 128 dB continuous, 134 dB peak
Impedance Passive - 8 ohms;
Impedance Bi-Amp - LF: 8 ohms HF: 6 ohms;
Crossover Type - Passive / Bi-amp, switchable;
Components - 1 x 12" (316 mm) LF driver; 1 x 1.4" (36 mm) HF compression driver
Connectors - 2 x Neutrik speakON* NL4;
Wiring Passive - Pins 1+ / 1- input, pins 2+ / 2- link;
Wiring Bi-Amp - Pins 1+ / 1- LF, pins 2+ / 2- HF;
Construction - 15 mm (5/8") birch plywood;
Grille - Powder-coated perforated steel;
Flying Hardware - M10 x 2
