• Microphone Input Type : XLR/1/4 " combo connector, electronically balanced
• Mic E.I.N. (20 Hz - 20 kHz)
• - @ 0 Î source resistance -130 dB / -133.1 dB A-weighted
• - @ 50 Î source resistance -128 dB / -131.5 dB A-weighted
• - @ 150 Î source resistance -127 dB / -129.8 dB A-weighted
• Frequency response  : (“1 dB) 18 Hz - 40 kHz
• Frequency response : (“3 dB) < 10 Hz - 75 kHz
• Gain range : +15 dB to +55 dB
• Max. input level : +12 dBu @ +10 dB Gain
• Impedance : 2 kÎ
• Signal-to-noise ratio : 98 dB / 101 dB A-weighted (0 dBu in @ +22 dB Gain)
• Distortion (THD+N) : 0.013%
• Frequency Response (Mic In, Main Out) : 18 Hz - 40 kHz: +0 dB / -1 dB; 10 Hz - 75 kHz: +0 dB / -3 dB
• Stereo Line Input Type : RCA jacks, unbalanced
• Impedance : 6 kÎ
• Gain range : -ˆž to +20 dB
• Max. input level : +20 dBu
• 2-Track In Type : RCA jacks, unbalanced
• Impedance : 20 kÎ
• Max. input level : +20 dBu
• Headset Mic In Type : 1„8" TRS mini jack
• Impedance : 6 kÎ
• Max. input level : +22 dBu @ Gain Min
• Equalizer Low : 80 Hz / ±15 dB
• Equalizer High : 12 kHz / ±15 dB
• Main Outputs Type : RCA, unbalanced
• Impedance : 470 Î
• Max. output level : +22 dBu
• Phones Output Type : 1„8" TRS mini jack
• Max. output level : +7 dBu / 150 Î
• System Data (Noise) Main mix @ -ˆž, channel fader @ -ˆž: -96 dBu / -101 dBu A-weighted
• Main mix @ 0 dB, Î channel fader @ -ˆž: -80 dBu / -85 dBu A-weighted
• Main mix @ 0 dB, channel fader @ 0 dB: -80 dBu / -85 dBu A-weighted
• External USB Switching Power Supply
• Mains voltage : 100-240 V, 50/60 Hz
• Power consumption : 0.9 W
• Power connector : USB, type A
• Converter : 16-bit
• Sample Rate : 48 kHz
