Ahuja PAM-3001Z Installation Amplifier | www.djpundits.com

Description: 325W RMS at 10% THD

Warranty : 1 year

Offer Price : 18,050.00

100% Original Product Guarantee from DJ Pundits.
COD available in select areas. Put your pin code in the shipping calculator to see COD availability.
Secure shopping with all major Indian credit cards, NEFT, Cheque payments accepted.
The products you buy are sourced carefully for you at the lowest price

Tags : PAM3001Z Installation Amplifier pam series

5 Mic, 3 Aux & 1 Telephone Inputs.
Features and specifications are similar to PAM-3001.
PAM-3001Z has the additional feature of distributing the total load of 100V line amongst 5 speaker zones, allowing the output to designated areas. The zones are selectable through a zone selector push-button switch on the front panel.
Ideal for use in commercial establishments where the building may be sectionised in different areas such as office, warehouse, workshop etc.
19” Rack mountable.

Power Output : 415W Max., 325W RMS at 10% THD, 300W RMS at 5% THD, 275W RMS at 2% THD
Output Regulation : ≤ 2 dB, no load to full load at 1kHz
Input Channels : 3 × Mic 0.65mV/4.7kΩ, 2 × Mic 1.0mV/2kΩ, 1 × Line 1V/50kΩ, 2 × Aux 100mV/470kΩ, 1 × Aux 250mV/470kΩ, 1 × Telephone 150mV/10kΩ
Frequency Response : 50-15,000Hz ±3dB
Signal to Noise Ratio : 60dB
Tone Controls : Bass- ±10dB at 100Hz; Treble- ±10dB at 10kHz
Outputs : Preamp 200mV/600Ω, Line 1V/1kΩ, Monitor 5V/8Ω
Speaker Outputs : 4Ω, 8Ω, 70V & 100V
Zone Selection : 5 + All Zone
Power Supply : AC- 220-240V 50/60Hz; DC- 24V (2×12V Car Battery)
Power Consumption : AC- 600VA; DC- 7A
Dimensions : W482 × H133 × D390 mm
Weight : 19.8kg
