Frequency Response - 60 Hz - 20 kHz ±3 dB / 5 Hz - 20 kHz -10 dB;
Nominal Dispersion - 70º H X 70º V @ -6 dB Points;
Directivity Factor (Q) - 9.4; Directivity Index (DI) - 9.7
Power Handling (IEC) Passive - 500 W continuous, 2000 W peak;
Power Handling (IEC) Bi-amp - LF: 500 W continuous, 2000 W peak / HF: 40 W continuous, 160 W peak
Sensitivity - 97 dB (1 W @ 1 m);
Maximum SPL Passive - 124 dB continuous, 130 dB peak;
Maximum SPL Bi-Amp - LF: 124 dB continuous, 130 dB peak / HF: 122 dB continuous, 128 dB peak
Impedance Passive - 8 ohms; Impedance Bi-Amp - LF: 8 ohms HF: 6 ohms;
Crossover Type - Passive / Bi-amp, switchable;
Components - 1 x 15" (394 mm) LF driver; 1 x 1" (25 mm) HF compression driver
Connectors - 2 x Neutrik speakON* NL4;
Construction - 15 mm (5/8") birch plywood;
Grille - Powder-coated perforated steel;
Flying Hardware - M12 x 12
